Pipelining TensorCore and SparseCore operations

Pipelining TensorCore and SparseCore operations#

This page explains an optimization technique to overlap SparseCore (SC) embedding computations with the TensorCore (TC) computations to improve training throughput.

The API provides a step() function that takes the SparseCore forward pass, TensorCore forward/backward pass, and SparseCore backward pass functions as input. The step() function manages the pipeline state and executes the functions in the correct order.

The embedding_pipelining_utils module provides utilities for managing this overlap.

For an example of usage see: jax_sc_shakespeare_pipelined_jit_test.py

Converting to Pipelined Training#

Turning a regular, non-pipelined training loop into a pipelined one requires moving from a single step function to a pipelined step function that manages state across iterations.

Non-pipelined Training Loop:

The following is an example that demonstrates converting a regular training loop to a pipelined one using the embedding_pipelining_utils module.

for step in range(num_steps):
  batch = prepare_batch(step)

  # 1. SparseCore Forward
  sc_activations, _ = sc_fwd_fn(batch.sparse, variables)

  # 2. TensorCore Forward/Backward
  sc_grads, output, state, _ = tc_fn(sc_activations, batch.dense, state)

  # 3. SparseCore Backward (Update)
  variables, _ = sc_bwd_fn(batch.sparse, sc_grads, variables)

  # Process output...

Pipelined Training Loop:

def prepare_input(step_counter):
  if step_counter < num_steps:
    return ep_utils.CurrentStepInput(
        sparse_inputs=fetch_sparse(step_counter),
        dense_inputs=fetch_dense(step_counter),
    )
  else:
    # Provide dummy inputs for pipeline draining steps
    return jax.tree.map(jnp.zeros_like, first_batch_input)

pipeline_state = ep_utils.get_initial_state(...)

# Pipelining requires 2 extra steps (filling and draining)
for step_counter in range(num_steps + 2):
  # Prepare input for the current iteration
  pipeline_input = prepare_input(step_counter)
  fake_tc_step = not ep_utils.is_output_valid(step_counter, num_steps)

  # Single call to ep_utils.step handles all stages
  output, _, state, variables, pipeline_state = ep_utils.step(
      pipeline_input, state, variables, pipeline_state,
      sc_fwd_fn, tc_fn, sc_bwd_fn, fake_tc_step=fake_tc_step)

  if ep_utils.is_output_valid(step_counter, num_steps):
    # Process output from step_counter - 1
    process_metrics(output)

Special handling for boundary steps#

The overlapping execution of SparseCore and TensorCore computations from different batches requires special handling for the first and last steps of the training loop.

Skipping TensorCore execution during pipeline filling and draining#

The tc_function (which runs the main model’s forward and backward pass) should only run when it has valid inputs from the previous step’s SC forward pass, and when its gradients are needed for a future SC backward pass. In the very first and very last pipeline steps, one of these conditions isn’t met. The flag fake_tc_step=True is used to skip the actual TC computation in these steps.

The utility function is_output_valid() returns True only for steps 1 to num_steps, signaling that TC should only run in those steps.

# Pipeline step 0: filling (SC fwd only)
# Pipeline steps 1 to num_steps: steady state
# Pipeline step num_steps + 1: draining (SC bwd only)
fake_tc_step = not ep_utils.is_output_valid(step_counter, num_steps)

Providing dummy inputs during pipeline draining#

We only have num_steps batches of real input data (0 to num_steps-1). However, the pipeline requires num_steps + 2 iterations to complete. In the last two steps (num_steps and num_steps+1), we need to provide dummy inputs to satisfy the function signatures.

if step_counter < num_steps:
  pipeline_input = prepare_real_batch(step_counter)
else:
  # Use zeros_like to provide dummy inputs for extra steps
  pipeline_input = jax.tree.map(jnp.zeros_like, dummy_input_template)

Passing data between stages using auxiliary output (Aux)#

The SparseCore (SC) and TensorCore (TC) functions can return auxiliary data (aux) that is passed to subsequent stages in the pipeline. This is useful for passing state or intermediate results that are not part of the primary training data (like activations or gradients).

sc_fwd_aux: Returned by the SC forward function. It is passed as an argument to the TC function in the next pipeline step.
tc_aux: Returned by the TC function. It is passed as an argument to the SC backward function in the next pipeline step.
sc_bwd_aux: Returned by the SC backward function. It is returned as part of the step() function’s output and can be used for logging or monitoring.

The types of these auxiliary data are defined by the user when instantiating the stage functions (ScFwdStageFun, TcStageFun, ScBwdStageFun). By default, if no auxiliary data is needed, None should be returned.

Example: Passing metadata from SC Forward to TC

def sc_fwd_fn(sparse_inputs, variables):
  # Perform lookup...
  activations = ...
  # Pass metadata (e.g., sequence lengths) to TC
  sc_fwd_aux = {"seq_lengths": sparse_inputs.lengths}
  return activations, sc_fwd_aux

def tc_fn(activations, dense_inputs, state, sc_fwd_aux):
  # Use metadata from SC Forward
  seq_lengths = sc_fwd_aux["seq_lengths"]
  # ... perform TC computations ...
  return gradients, output, state, tc_aux

Sharding and Performance#

Efficient pipelining requires correct sharding of the pipeline state and embedding variables to ensure data is properly distributed across TPU devices and SparseCores.

Sharding the Pipeline State#

The PipelineState object contains buffered inputs and outputs for different pipeline stages. To avoid unnecessary data copies during training, it is important to initialize this state with the correct shardings. The helper function get_pipeline_state_sharding() generates a sharding structure for the pipeline state based on the shardings of your dense inputs, sparse inputs, and model outputs.

# Define your shardings
global_sharding = jax.sharding.NamedSharding(mesh, P("data"))
replicated_sharding = jax.sharding.NamedSharding(mesh, P())

# Generate pipelined state sharding
pipeline_state_sharding = ep_utils.get_pipeline_state_sharding(
    pipeline_state_cls=MyPipelineState,
    dense_input_sharding=global_sharding,
    sparse_input_sharding=global_sharding,
    pipeline_output_sharding=MyModelOutput(metrics=replicated_sharding),
    tc_aux_sharding=replicated_sharding,
)

# Use this sharding when initializing the pipeline state
pipeline_state = ep_utils.get_initial_state(...)
pipeline_state = jax.device_put(pipeline_state, pipeline_state_sharding)

Embedding Table Layout#

For optimal SparseCore performance, embedding variables should be sharded using a specific layout that matches the hardware’s expectations. The utility function embedding_table_format (or embedding_table_format_with_sharding) in the utils module provides this optimized format.

from jax_tpu_embedding.sparsecore.utils import utils

# Create an optimized sharding for embedding variables
emb_sharding = jax.sharding.NamedSharding(mesh, P("data", None))
emb_layout = utils.embedding_table_format_with_sharding(emb_sharding)

# Initialize embedding variables with this layout
emb_variables = embedding.init_embedding_variables(
    key, table_specs, emb_sharding, num_sc_per_device)

Using these shardings in your jax.jit()’ed train step via in_shardings and out_shardings helps JAX optimize the execution and minimize overhead.

Additionally, you can use jax.lax.with_sharding_constraint inside your TensorCore function to ensure that activations or intermediate tensors maintain the desired sharding layout during the computation.

Performance and Correctness Considerations for Boundary Steps#

While it might seem tempting to use a single unified step function with internal conditional logic (like jax.lax.cond) to handle boundary steps, doing so introduces several significant limitations:

XLA Optimization and Offloading: Primitives like jax.lax.cond can act as barriers that prevent the XLA compiler from effectively scheduling SparseCore (SC) programs in parallel with TensorCore (TC) operations. Avoiding these branches is a prerequisite for advanced optimizations such as SC Collective Offloading, where communication primitives are scheduled on SparseCores to hide latency.
Layout and Performance: Internal branching can lead to inconsistent layout assignments across step boundaries. If activations from a previous step are in a TensorCore layout when the next step expects a SparseCore layout, it can cause “weird interactions” or performance degradation due to unexpected conversions.
Numeric Correctness: Using jax.lax.cond within SparseCore embedding programs has been observed to produce incorrect results or numeric inconsistencies in some cases. Handling these steps at the host level (by toggling a static fake_tc_step flag) ensures consistent behavior and model convergence.

Note

The fake_tc_step argument should be marked as static in your jax.jit’ed train function. This ensures that JAX generates separate, optimized straight-line HLO for the filling, steady-state, and draining phases of the pipeline.

Optimal Ordering of Stacking and Unstacking#

For maximum performance, the ordering of data formatting operations relative to the pipeline stages is critical. It is recommended to shift unstacking and stacking logic into the TensorCore (TC) stage:

SC Forward: Should return “raw” stacked activations. Disable automatic unstacking (e.g., set unstack_embedding_activations=False).
TC Stage (Unstack): Unstack the activations as the FIRST operation inside your tc_function.
TC Stage (Stack): Stack the gradients as the LAST operation inside your tc_function.
SC Backward: Should receive stacked gradients and perform the update. Disable automatic stacking (e.g., set stack_embedding_gradients=False).

This pattern typically looks like the following:

def sc_fwd_fn(sparse_inputs, variables):
  # Disable unstacking in the SC stage
  return embedding.embedding_lookup(
      sparse_inputs, variables, unstack_embedding_activations=False), None

def tc_fn(activations, dense_inputs, state, sc_fwd_aux):
  # 1. Unstack activations as the FIRST operation in TC
  activations = embedding.unstack_embedding_activations(activations)

  # ... Model logic ...

  # 2. Stack gradients as the LAST operation in TC
  grads = embedding.stack_embedding_gradients(grads)
  return grads, output, state, tc_aux

def sc_bwd_fn(sparse_inputs, grads, variables):
  # Disable stacking in the SC stage
  return embedding.apply_gradients(
      grads, sparse_inputs, variables, stack_embedding_gradients=False), None

Following this order—(SC_BWD -> SC_FWD)@SC and (Unstack -> TC_Logic -> Stack)@TC—allows XLA to optimize scheduling and enables collectives offloading without requiring explicit queueing mechanisms. This alignment has been shown to reduce step time by 5-6ms in production workloads.

Warning

Initializers: Avoid using all-zero initializers for embedding tables when pipelining is enabled. The interaction between delayed updates and zero-initialized tables can lead to unstable convergence. Use non-zero initialization schemes to ensure healthy training dynamics from step 0.

Warning

When pipelining is enabled, do not manually toggle perform_unstacking or perform_stacking within your SparseCore stages. The state carried by the pipeline (activations and gradients) should remain in the format expected by the pipeline utilities to avoid suboptimal layout conversions.

If host-side branching is not feasible, an alternative strategy is to use a gradient multiplier (passing 0 during filling/draining and 1 during steady state) to the optimizer. This avoids the use of jax.lax.cond while still preventing weight updates during boundary steps.

Internal Implementation Details#

This section describes how the pipeline stages overlap and the cycles required to process multiple batches.

Pipelining works by passing n batches (0 based indexing).

Note

Output from SC bwd (i-2) is used in SC fwd (i) i.e. [SC BWD (i-2) -> SC FWD i] (SC) and [TC FWD BWD (i-1)] (TC) are run in parallel

`Cycles`	`SC fwd`	`TC fwd/bwd`	`SC bwd`	`SC bwd -> SC fwd`
`0`	`0`	`-` (`fake_tc_step=True`)	`-`	`SC fwd(0)`
`1`	`1`	`0`	`-`	`SC fwd(1)`
`2`	`2`	`1`	`0`	`0 -> 2`
`3`	`3`	`2`	`1`	`1 -> 3`
`...`	`...`	`...`	`...`	`... -> ...`
`n-1`	`n-1`	`n-2`	`n-3`	`n-3 -> n-1`
`n (E)`	`-` (fake input)	`n-1`	`n-2`	`SC bwd(n-2)`
`n+1 (E)`	`-` (fake input)	`-` (`fake_tc_step=True`)	`n-1`	`SC bwd(n-1)`

E: Extra Steps

API#

step(pipeline_input, tc_train_state, embedding_variables, pipeline_state, sc_fwd_function, tc_function, sc_bwd_function, *, fake_tc_step)#

Step the pipeline.

Parameters:

pipeline_input (CurrentStepInput[_SparseInput, _DenseInput]) – Inputs for the current step (sc_fwd, tc, sc_bwd).
tc_train_state (_TcTrainState) – Training state for the TensorCore.
embedding_variables (_EmbeddingVariables) – Embedding variables for the SparseCore.
pipeline_state (PipelineState[_SparseInput, _DenseInput, _EmbeddingActivations, _EmbeddingGradients, _TcAux, _ScFwdAux, _PipelineOutput]) – Internal pipeline state that contains the inputs and outputs for and from the three stages that is sequentially shifted by one step at each pipeline execution.
sc_fwd_function (ScFwdStageFun[_SparseInput, _EmbeddingActivations, _EmbeddingVariables, _ScFwdAux]) – SparseCore forward pass function.
tc_function (TcStageFun[_EmbeddingActivations, _DenseInput, _EmbeddingGradients, _PipelineOutput, _TcTrainState, _ScFwdAux, _TcAux]) – TensorCore forward/backward pass function.
sc_bwd_function (ScBwdStageFun[_SparseInput, _EmbeddingGradients, _EmbeddingVariables, _TcAux, _ScBwdAux]) – SparseCore backward pass function.
fake_tc_step (bool) – If true, fake the TC step by copying the embedding gradients to the pipeline output.

Returns:

A tuple of (pipeline_output, auxiliary output from SC BWD, updated train_state, updated embedding_variables, updated pipeline_state).

Return type:

tuple[_PipelineOutput, _ScBwdAux, _TcTrainState, _EmbeddingVariables, PipelineState[_SparseInput, _DenseInput, _EmbeddingActivations, _EmbeddingGradients, _TcAux, _ScFwdAux, _PipelineOutput]]

get_initial_state(pipeline_input, tc_train_state, embedding_variables, sc_fwd_function, tc_function, dense_input_sharding=None, sparse_input_sharding=None)#

Get the initial pipeline state.

Parameters:

pipeline_input (CurrentStepInput[_SparseInput, _DenseInput]) – Input to the sc_fwd, tc and sc_bwd for the current step.
tc_train_state (_TcTrainState) – Training state for the TensorCore.
embedding_variables (_EmbeddingVariables) – Embedding variables for the SparseCore.
sc_fwd_function (ScFwdStageFun[_SparseInput, _EmbeddingActivations, _EmbeddingVariables, _ScFwdAux]) – SparseCore forward pass function.
tc_function (TcStageFun[_EmbeddingActivations, _DenseInput, _EmbeddingGradients, _PipelineOutput, _TcTrainState, _ScFwdAux, _TcAux]) – TensorCore forward/backward pass function.
dense_input_sharding (Sharding | None) – The sharding of the dense inputs.
sparse_input_sharding (Sharding | None) – The sharding of the sparse inputs.

Returns:

Initial pipeline state.

Return type:

PipelineState[_SparseInput, _DenseInput, _EmbeddingActivations, _EmbeddingGradients, _TcAux, _ScFwdAux, _PipelineOutput]

get_pipeline_state_sharding(pipeline_state_cls, dense_input_sharding, sparse_input_sharding, pipeline_output_sharding, tc_aux_sharding)#

Get the sharding for the pipeline state.

Parameters:

pipeline_state_cls (type[PipelineState[_SparseInput, _DenseInput, _EmbeddingActivations, _EmbeddingGradients, _TcAux, _ScFwdAux, _PipelineOutput]]) – The class of the pipeline state instantiated with user type parameters.
dense_input_sharding (Sharding) – The sharding of the dense inputs.
sparse_input_sharding (Sharding) – The sharding of the sparse inputs.
pipeline_output_sharding (Sharding) – The sharding of the output from the TensorCore.
tc_aux_sharding (Sharding) – The sharding of the auxiliary data from the TensorCore.

Returns:

The sharding of the pipeline state.

Return type:

PipelineState[_SparseInput, _DenseInput, _EmbeddingActivations, _EmbeddingGradients, _TcAux, _ScFwdAux, _PipelineOutput]

get_pipeline_train_steps(num_steps)#

Get the number of pipeline train steps.

Parameters:: num_steps (int)
Return type:: int

is_output_valid(pipeline_step, num_steps)#

Check if the output of the pipeline is valid.

Output is only valid when the TensorCore (TC) runs which is from step 1 to num_steps.

Parameters:

pipeline_step (int) – Current pipeline step (0 based indexing).
num_steps (int) – Total number of steps.

Returns:

True if the output is valid, False otherwise.

Return type:

bool

get_default_sc_fwd_function(feature_specs, global_mesh)#

Get the default SC fwd function.

Parameters:

feature_specs (FeatureSpec | Sequence[FeatureSpec] | Mapping[str, FeatureSpec]) – Feature specs for the embedding layer.
global_mesh (Mesh) – Global mesh for the embedding layer.

Returns:

A function that takes default pipeline stage input/output and embedding variables as input and returns updated default pipeline stage input/output.

Return type:

ScFwdStageFun[PreprocessedInput, Array | None, EmbeddingVariables | Sequence[EmbeddingVariables] | Mapping[str, EmbeddingVariables], None]

get_default_sc_bwd_function(feature_specs, global_mesh)#

Get the default SC bwd function.

Parameters:

feature_specs (FeatureSpec | Sequence[FeatureSpec] | Mapping[str, FeatureSpec]) – Feature specs for the embedding layer.
global_mesh (Mesh) – Global mesh for the embedding layer.

Returns:

A function that takes default pipeline stage input/output and embedding variables as input and returns updated embedding variables.

Return type:

ScBwdStageFun[PreprocessedInput, Array | None, EmbeddingVariables | Sequence[EmbeddingVariables] | Mapping[str, EmbeddingVariables], None, None]

class PipelineState(pipeline_step, last_step_inputs, step_before_last_step_inputs, placeholder_output, placeholder_tc_aux)#

Pipeline state.

Parameters:

pipeline_step (Array)
last_step_inputs (LastStepInput[_SparseInput, _DenseInput, _EmbeddingActivations, _ScFwdAux])
step_before_last_step_inputs (StepBeforeLastStepInput[_SparseInput, _EmbeddingGradients, _TcAux])
placeholder_output (_PipelineOutput)
placeholder_tc_aux (_TcAux)

pipeline_step#

Current pipeline step (0 based indexing). This is the step number of the pipeline, not the training step.

Type:: jax.Array

placeholder_output#

Placeholder output from the current pipeline step (TC) when run_tc=False and jax.lax.cond needs a placeholder value.

Type:: jax_tpu_embedding.sparsecore.lib.nn.embedding_pipelining_utils._PipelineOutput

placeholder_tc_aux#

Placeholder auxiliary data from the current pipeline step (TC) when run_tc=False and jax.lax.cond needs a placeholder value.

Type:: jax_tpu_embedding.sparsecore.lib.nn.embedding_pipelining_utils._TcAux

replace(**updates)#: Returns a new object replacing the specified fields with new values.

class CurrentStepInput(sparse_inputs, dense_inputs)#

Step i inputs.

Parameters:

sparse_inputs (_SparseInput)
dense_inputs (_DenseInput)

replace(**updates)#: Returns a new object replacing the specified fields with new values.

class LastStepInput(sparse_inputs, embedding_activations, dense_inputs, sc_fwd_aux)#

Step i-1 inputs.

Parameters:

sparse_inputs (_SparseInput)
embedding_activations (_EmbeddingActivations)
dense_inputs (_DenseInput)
sc_fwd_aux (_ScFwdAux)

replace(**updates)#: Returns a new object replacing the specified fields with new values.

class StepBeforeLastStepInput(sparse_inputs, embedding_gradients, tc_aux)#

Step i-2 inputs.

Parameters:

sparse_inputs (_SparseInput)
embedding_gradients (_EmbeddingGradients)
tc_aux (_TcAux)

replace(**updates)#: Returns a new object replacing the specified fields with new values.

class ScFwdStageFun(*args, **kwargs)#

Protocol for the SparseCore forward pass function.

__call__(sparse_inputs, embedding_variables)#

SparseCore forward pass function.

Parameters:

sparse_inputs (_SparseInput) – Sparse inputs for the SparseCore forward pass.
embedding_variables (_EmbeddingVariables) – Embedding variables for the SparseCore.

Returns:

A tuple of embedding activations and auxiliary data to TC.

Return type:

tuple[_EmbeddingActivations, _ScFwdAux]

class TcStageFun(*args, **kwargs)#

Protocol for the TensorCore forward/backward pass function.

__call__(embedding_activations, dense_inputs, train_state, sc_fwd_aux=None)#

TensorCore forward/backward pass function.

Parameters:

embedding_activations (_EmbeddingActivations) – Embedding activations from the SparseCore.
dense_inputs (_DenseInput) – Dense inputs for the TensorCore.
train_state (_TcTrainState) – Train state for the TensorCore.
sc_fwd_aux (_ScFwdAux) – Auxiliary data from the SparseCore forward pass.

Returns:

A tuple of embedding gradients, pipeline output, updated train state, and auxiliary data to SC BWD.

Return type:

tuple[_EmbeddingGradients, _PipelineOutput, _TcTrainState, _TcAux]

class ScBwdStageFun(*args, **kwargs)#

Protocol for the SparseCore backward pass function.

__call__(sparse_inputs, embedding_gradients, embedding_variables, tc_aux=None)#

SparseCore backward pass function.

Parameters:

sparse_inputs (_SparseInput) – Sparse inputs for the SparseCore backward pass.
embedding_gradients (_EmbeddingGradients) – Embedding gradients from the TensorCore.
embedding_variables (_EmbeddingVariables) – Embedding variables for the SparseCore.
tc_aux (_TcAux) – Auxiliary data from the TensorCore forward/backward pass.

Returns:

A tuple of updated embedding variables and auxiliary output.

Return type:

tuple[_EmbeddingVariables, _ScBwdAux]

Pipelining TensorCore and SparseCore operations

Contents

Pipelining TensorCore and SparseCore operations#

Converting to Pipelined Training#

Special handling for boundary steps#

Skipping TensorCore execution during pipeline filling and draining#

Providing dummy inputs during pipeline draining#

Passing data between stages using auxiliary output (Aux)#

Sharding and Performance#

Sharding the Pipeline State#

Embedding Table Layout#

Performance and Correctness Considerations for Boundary Steps#

Optimal Ordering of Stacking and Unstacking#

Internal Implementation Details#

API#
